Autel MaxiTPMS TS501 TPMS Diagnostic and Service Tool

Autel MaxiTPMS TS501 TPMS Diagnostic and Service Tool

Top 4 Reasons To Get Autel MaxiTPMS TS501:

1. Pre-selection process offers faster activation and diagnostics

2. Accurate diagnosing results – a tool users can trust

3.1-year free upgrade on the internet via USB port

4. Easy-to-use with intuitive navigation and step-by-step on-screen

Autel MaxiTPMS TS501 Feature and Function:

1. Activates ALL magnetic, frequency and tire deflation triggered sensors using 125KHz continuous or modulated wave signals
2. Receives both 315MHz and 433MHz signals
3. Reads data including sensor ID, tire pressure, temperature, battery condition, OE part number, relearn information
4. Reads / writes sensor ID from vehicle ECU
5. Reads / clears codes of TPMS system and reset malfunction indicator light
6. Checks Remote Keyless Entry (Key FOB) for transmissions
7. Graphs vehicle with 4 or 5 wheels to simplify the diagnostic process
8. Pre-selection process offers faster activation and diagnostics
9. Programs vehicle ECU to learn sensor IDs and positions
10. Provides visual and audible responses to confirm sensors are working properly
11. On-screen code definitions
12. Proper LF signal to prevent being fooled by other RF signals
13. Incredibly easy to use with intuitive navigation and step-by-step on-screen instructions
14. Built-in rechargeable Li-polymer battery
15. Automatic power-off to preserve battery life
16. Multilingual support: English, French, and Spanish, etc.
17. One year free update on the internet via USB port
18. Ergonomic design features strong housing and protective rubber boot

Autel MaxiTPMS TS501 Specification:

Display: TFT color display (320 x 240 dpi)
Power: 3.7V Li-polymer battery
Operating Temperature: 0 to 50°C (32 to 122 °F)
Storage Temperature: -20 to 70°C (-4 to 158 °F)
Length\Width\Height: 202.2mm(7.96″)\106.7mm(4.20″)\37.7mm(1.48″)
Main unit weight: 0.4kg (0.88lb)

Autel TPMS Function Comparison:

Package list:

1pc x TPMS TS501 main unit
1pc x USB Cable
1pc x SD CARD
1pc x Charger
1pc x Magnet
1pc x OBDII Cable
1pc x CD
1pc x User’s Manual
